Y/C Adapter for MiSTer FPGA with S-Video Cable

This Y/C Adapter for MiSTer FPGA allows for outputting S-Video for playing on a CRT TV. You must update to the latest version of the cores and mister.ini file.

 This adapter can be used with the MiSTer Analog IO board.

Setup :

1.  Power the adapter by setting VGA PWR jumper on the Analog IO board to 5V or 3.3V. (5V is recommended)
2. Connect audio to the audio jack on the Analog IO board
3. Set vga_mode=svideo / ntsc_mode=0 / composite_sync=1 / vga_scaler=0 in the mister.ini file

Features :

• Most of Console cores and tens of arcade cores supports Y/C adapter
• Tuned for NTSC (works with PAL)
• Outputs S-Video
• Active Y/C Encoder

• 1.4 Meter S-Video cable included
